Standard vesselsConfigurator
We offer you standard vessels from 50 liters to 3,000 liters with 11 and 16 bar. High-pressure vessels, vacuum vessels, and other pressure vessels are also available and can be coated according to your requirements.
▲
- 150 l
- 250 l
- 350 l
- 500 l
- 750 l
- 1,000 l
- 1,500 l
- 2,000 l
- 3,000 l
▼
Details
High Pressure vessels 2,000 Liters, 23 bar, liegend
MB 141224-3.2000
Features
Built according to
Designed to AD 2000; conformity assessment to PED 2014/68/EU, Module H1
Designed to AD 2000; conformity assessment to PED 2014/68/EU, Module H1
Operating Conditions
AD 2000 – S1 (10/2000): ≤ 1,000 start-ups and shut-downs between depressurised state and PS; operating pressure fluctuation range up to 20% of PS as specified by the design
AD 2000 – S1 (10/2000): ≤ 1,000 start-ups and shut-downs between depressurised state and PS; operating pressure fluctuation range up to 20% of PS as specified by the design
Ambient Temperatures
-20°C to +50°C
-20°C to +50°C
Dimensions
Approx. Weight
795 kg
795 kg
Diameter
1,100 mm
1,100 mm
Height
1,300 mm
1,300 mm
Augmented Reality (AR)
Shipping Information
Dimensions (LxWxH)
2,380 x 1,100 x 1,340 mm
2,380 x 1,100 x 1,340 mm
Approx. Weight
795 kg
795 kg
Country of Origin
Germany
Germany
Customs Tariff Number
731 100 91
731 100 91
Drawing
MB 141224-3.2000G
Primed
MB 141224-3.2000V
Galvanized
Illustrations and details may differ from the original.
